Jinan Tindo International Co., Ltd. is one of the most credible manufacturers and suppliers of nuts roaster machine in China. Please feel free to buy high quality nuts roaster machine at competitive price from our factory. If you have any enquiry about quotation, please feel free to email us.
roasted nut processing equipment, nuts roasting equipment, nuts roaster equipment, nuts rotary roaster, nuts rotary roasting machine
This Nuts Roaster Machine is heated by electromagnetism which adopts EDDY CURRENT heating principle. The high-frequency magnetic field generates eddy current on the surface of the rotary drum, and the induced eddy current makes the drum heat, thus heating the nuts.
I. Characteristics of Nuts Roaster Machine
● Rapid heating speed and adjustable heating temperature: Several temperature sensing probes are installed in the drum to measure the drum temperature and material temperature respectively.
● The thermal efficiency reaches 95%.
● Intelligent control: Heating temperature, feeding amount of raw materials, and roasting time, all can be adjusted.
● Electromagnetic heating: No open flame, no carbon emission, and no pollution.
● Double automatic protection functions: System over-temperature protection and rotary drum over-temperature protection.
● Multi-layer thermal insulation materials: Prevent heat energy consumption and save heating costs.
II. Parameters of Nuts Roaster Machine
Model | Capacity | Heating Power | Motor Power | Rotary Drum | Machine |
TDNRE-7-10 | 600-100 kg/batch | 5-35KW | 1.1KW | Φ700x1000mm | 2100*1450*1460mm |
TDNRE-7-15 | 100-150 kg/batch | 5-45KW | 1.5KW | Φ700x1500mm | 2600*1450*1460mm |
TDNRE-9-15 | 150-200 kg/batch | 5-55KW | 2.2KW | Φ900x1500mm | 2700*1690*1670mm |
TDNRE-10-15 | 200-300 kg/batch | 5-60KW | 3KW | Φ1000x1500mm | 2700*1790*1770mm |
TDNRE-12-15 | 300-400 kg/batch | 5-70KW | 4KW | Φ1200x1500mm | 2850*1990*1970mm |
TDNRE-12-20 | 400-500 kg/batch | 5-80KW | 4KW | Φ1200x2000mm | 3350*1990*1970mm |
III. Application of Nuts Roaster Machine
This equipment can be used for preheating, roasting, drying seeds, nuts, peanuts, chestnuts, beans, cashew nut, pistachio nuts, chickpeas, larvae, etc.
III. Product Details of Nuts Roaster Machine
Hot Tags: nuts roaster machine, China, manufacturers, suppliers, factory, price, Nuts Roasting Machine, peanut roaster machine, Peanut Roasting Machine, batch roasting drum, electric roasting machine, roasting machine
